Product Description
X9SRE | SUPERMICRO | Atx INTEL C602 Ddr3 LGa-2011 MotherboardOther Details
0Product Videos
Custom Field
Form Factor ATX
CPU Socket Type LGA 2011
Supported CPU(s) Intel Xeon Processor
Supported CPU Technologies 64-bit
AES New Instructions
Demand Based Switching
Enhanced Intel Speedstep Technology
Execute Disable Bit
Hyper-Threading Technology
Idle States
Intel 64 Architecture
Intel Trusted Execution Technology
Intel Turbo Boost Technology
Intel Virtualizati
Chipset Intel C602
Number of Memory Slot(s) 8
Supported Memory Standard(s) PC3-10600 (DDR3-1333)
PC3-12800 (DDR3-1600)
PC3-8500 (DDR3-1066)
Maximum Installed Memory 512GB
Expansion Slots PCI Express x16
PCI Express x4
PCI Express x8
Expansion Slots Details 1 (x16) PCI-E 3.0 slot
1 (x8) PCI-E 3.0 (in x16) slot
1 (x4) PCI-E 2.0 (in x16) slot
3 PCI-X 64bit 133/100 slots
Storage Controller Serial-ATA 3.0 Gbps
Serial-ATA 6.0 Gbps
Storage Controller Details 2 SATA 3.0 ports (6Gb/s)
4 SATA 2.0 ports (3Gb/s)
4 SATA ports (3Gb/s) via SCU
On-Board Video Controller Nuvoton NCT6776F
Network Gigabit Ethernet
Connectors/Ports RJ-45 (Ethernet)
USB 2.0
Connectors/Ports Details 2 RJ45 Gigabit Ethernet LAN ports
9 USB 2.0 ports total
(2 rear + 6 via header + 1 Type A)
1 VGA port
2 PS/2 Keyboard/Mouse ports
1 serial port (rear) and 1 serial header (side)
1 DOM (Disk on Module) power connector
1 TPM Header
