X9DRD-7LN4F-SSG | SUPERMICRO | E-Atx INTEL Xeon E5-2600/E5-2600V2 Ddr3 LGa-2011 Server MotherboardProduct Videos
Custom Field
Form Factor EATX
CPU Socket Type LGA 2011
Supported CPU(s) Intel Xeon Processor
Supported CPU Technologies 64-bit
AES New Instructions
Demand Based Switching
Enhanced Intel Speedstep Technology
Execute Disable Bit
Idle States
Intel 64 Architecture
Intel Trusted Execution Technology
Thermal Monitoring Technologies
Chipset Intel C602J
Number of Memory Slot(s) 16
Supported Memory Standard(s) PC3-10600 (DDR3-1333)
PC3-12800 (DDR3-1600)
PC3-6400 (DDR3-800)
PC3-8500 (DDR3-1066)
Maximum Installed Memory 1TB
Expansion Slots PCI Express x8
Expansion Slots Details 6 (x8) PCI-E 3.0 slots
Storage Controller Serial-ATA 3.0 Gbps
Serial-ATA 6.0 Gbps
Storage Controller Details 2 SATA 3.0 ports (6Gb/s)
4 SATA 2.0 ports (3Gb/s)
8 SAS2 ports (6Gb/s)
On-Board Video Controller Matrox G200eW
Network Gigabit Ethernet
Connectors/Ports RJ-45 (Ethernet)
USB 2.0
Connectors/Ports Details 4 RJ45 Gigabit Ethernet LAN ports
1 RJ45 Dedicated IPMI LAN port
9 USB 2.0 ports total
(4 rear + 4 via header + 1 Type A)
1 VGA port
1 Fast UART 16550 port / 1 Header
1 DOM (Disk on Module) power connector
1 TPM Header
