Product Description
P5GD1-BVM/S | Asus | System Board Socket 775Product Videos
Custom Field
Form Factor ATX
CPU Socket Type LGA 775
Supported CPU(s) Intel Celeron Processor
Intel Pentium 4 Processor
FSB Speed (Maximum) 800 MHz
Supported CPU Technologies Hyper-Threading Technology
Chipset Intel 915P Express
South Bridge Chipset Intel ICH6R
Number of Memory Slot(s) 4
Number of Memory Channel(s) 2
Supported Memory Standard(s) PC-2700 (DDR-333)
PC-3200 (DDR-400)
Maximum Installed Memory 4 GB
Expansion Slots PCI-E x1
PCI-E x16
Expansion Slots Details 1 x PCI Express x16 slot for discrete graphics card
3 x PCI Express x1
3 x PCI
Storage Controller Details Intel® ICH6R South Bridge
1 x UltraDMA 100/66/33
4 x Serial ATA with Intel® Matrix Storage Technology with RAID 0, 1 support
ITE IDE RAID controller
2 x UltraDMA 133/100/66 with JBOD, RAID 0, 1, 0+1 support
Audio Controller Realtek ALC861
Connectors/Ports 24-pin ATX Power Connector
Audio-In
Audio-Out
Chassis Fan Connector
CPU Fan Connector
Parallel
Serial
USB 1.1
USB 2.0
Connectors/Ports Details Back Panel I/O Ports
1 x Parallel
1 x Serial
1 x S/PDIF Output
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x 8-Channel Audio I/O
1 x RJ45
4 x USB 2.0/1.1
Internal I/O Connectors
2 x USB 2.0 connectors supports additional 4 USB 2.0 ports
CPU / Chassis / Power
