Product Description
MBD-X11SSV-M4F-O | SUPERMICRO | INTEL C236 Chipset System Board (Motherboard) Socket Bga 1440 Mini-AtxProduct Videos
Custom Field
Chipset Manufacturer Intel
Processor Socket Socket BGA-1440
Integrated Processor Manufacturer Intel
Integrated Processor Type Xeon
Integrated Processor Model E3-1585 v5
Integrated Processor Speed 3.50 GHz
Integrated Processor Core Quad-core (4 Core)
Number of Memory Slots 2
Memory Form Factor SoDIMM
Maximum Memory 32 GB
Memory Speed Supported 1.87 GHz
2.13 GHz
1.60 GHz
Memory Technology DDR4 SDRAM
Controller Type Serial ATA/600
RAID Supported Yes
RAID Levels 10
5
1
0
Onboard Video On-board Video Chipset
Graphics Controller Manufacturer ASPEED
Graphics Controller Model AST2400
Gigabit Ethernet Yes
Number of Total Expansion Slots 2
Total Number of PCI Express Slots 1
Total Number of USB Ports 4
Number of USB 3.0 Ports 4
DVI Yes
Number of SATA Interfaces 4
Number of M.2 Interfaces 1
Total Number of Onboard USB Ports 5
Form Factor Mini ITX
Width 6.7
Depth 6.7
Environmentally Friendly Yes
Environmental Certification RoHS
