Product Description
MBD-X11SAT-F-B | SUPERMICRO | INTEL C236 Chipset System Board (Motherboard) Socket H4 LGa 1151Product Videos
Custom Field
Chipset Manufacturer Intel
Total Processor Supported 1
Processor Socket Socket H4 LGA-1151
Processor Supported Xeon
Core i7
Core i5
Core i3
Number of Memory Slots 4
Memory Form Factor DIMM
UDIMM
Maximum Memory 64 GB
Memory Speed Supported 2.13 GHz
1.87 GHz
1.60 GHz
Memory Technology DDR4 SDRAM
Controller Type Serial ATA/600
RAID Supported Yes
RAID Levels 0
1
5
10
Onboard Video On-board Video Chipset
Graphics Controller Manufacturer ASPEED
Graphics Controller Model AST2400
Gigabit Ethernet Yes
Number of Total Expansion Slots 5
Total Number of PCI Express Slots 4
Number of PCI Express x1 Slots 1
Number of PCI Express x16 Slots 3
Total Number of USB Ports 5
Number of USB 3.0 Ports 2
Number of USB 3.1 Ports 1
VGA Yes
HDMI Yes
DisplayPort Yes
DVI Yes
Number of SATA Interfaces 6
Number of M.2 Interfaces 1
Total Number of Onboard USB Ports 8
Number of Onboard USB 3.0 Ports 4
Form Factor ATX
Width 12
Depth 9.6
Environmentally Friendly Yes
Environmental Certification RoHS
