Product Description
Additional Information:
- Dimensions 326.6 x 382.7 x 88.8 mm
- Dimensions with anchor 326.6 x 382.7 x 105.5 mm
- Weight 3.4kg
- Weight with anchor: 3.8kg
- Polycarbonate shell with UV protection
- Maximum consumption 40W (Not including PoE power)
- Electrical connection (1) DC terminal or (2) RJ45
- Power supply Min. 54V / 0.8A (Not including PoE power)
- VDC Input 54V, 6A
- Passive PoE Input: (2) 54V / 1.5A, 4 Pairs (+1, 2, 4, 5; -3, 6, 7, 8) Passive PoE, eth0 and PoE In (PoE In only for power)
- Passive PoE Output: 2) 54V or 24V / 1.4A, 4 Pairs (+1, 2, 4, 5; -3, 6, 7, 8) Passive PoE, eth1 to eth4 (12) 802.3af/at or 24V/ 0.7A, 2 Pairs (+4, 5; -7, 8) Passive PoE, Ports 5 to 16
- Supported voltage range 42 to 56VDC
- Reset button
- Ports: (1) RJ45 Serial Console Port, (1) RJ45 Port PoE In, (16) 10/100/1000 RJ45, (2) 10G SFP+
- ARM Cortex-A9 400 MHz, MIPS64 processor with hardware acceleration for packet processing
- Memory 256 MB DDR3 RAM
- Flash memory 32 MB
- CE, FCC, IC certifications
- Mast mounting kit included
- Operating temperature -20 to 65° C
- Operating humidity 10 to 90% without condensation
Other Details
0Product Videos
Custom Field
Total Number of Network Ports 16
Uplink Port No
Modular Yes
Stack Port No
Port/Expansion Slot Details 16 x Gigabit Ethernet Network
Media Type Supported Twisted Pair
Ethernet Technology Gigabit Ethernet
Network Technology 10/100/1000Base-TX
Number of Total Expansion Slots 2
Expansion Slot Type SFP+
Shared SFP Slot No
Number of SFP+ Slots 2
Layer Supported 3
Manageable No
Power Source PoE
Power Supply
Redundant Power Supply Supported No
Form Factor Pole Mount
Wall Mountable
Height 3.5
Width 12.9
Depth 15.1"
