Product Description
DG33BU | Intel | Desktop Motherboard Socket LGA-775 1333MHz FSB micro ATXProduct Videos
Custom Field
Form Factor Micro ATX
CPU Socket Type LGA775
Supported CPU(s) Intel Celeron Processor
Intel Core2 Duo Desktop Processor
Intel Core2 Quad Processor
Intel Pentium Dual-Core Processor
FSB Speed (Maximum) 1333 MHz
Supported CPU Technologies Dual Core
Enhanced Intel Speedstep Technology
Execute Disable Bit
Hyper-Threading Technology
Idle States
Intel 64 Architecture
Quad Core
Thermal Monitoring Technologies
Chipset Intel G33 Express
South Bridge Chipset Intel ICH9DH
Number of Memory Slot(s) 4
Supported Memory Standard(s) PC2-5300 (DDR2-667)
PC2-6400 (DDR2-800)
Maximum Installed Memory 8 GB
Expansion Slots PCI
PCI Express x1
PCI Express x16
Storage Controller (ATA-7) Ultra ATA/133
Floppy Connector
Serial-ATA 3.0 Gbps
On-Board Video Controller Intel Graphics Media Accelerator 3100
Shared Video Memory 256 MB
Audio Controller Realtek ALC888
Network Gigabit Ethernet
Connectors/Ports Audio-In
Audio-Out
FireWire (IEEE 1394)
Microphone
PS/2
RJ-45 (Ethernet)
USB 2.0
Video-Out
Features Memory:
Dual Channel Architecture
BIOS:
ACPI support
SMBIOS support
Sleep / Wake Up:
Mouse Wake Up
Wake on USB Port
Keyboard Wake Up
Wake on PCI Device
Suspend to RAM (STR)
Hardware:
System Voltage
CPU Fan Tachometer
Chassis Temperature
CPU Core Temp
