Product Description
5188-5622 | HP | System Board micro ATX Socket-AM2 Nodsum3 GL8E for Desktop SystemsProduct Videos
Custom Field
Form Factor Micro ATX
CPU Socket Type Socket AM2
Supported CPU(s) AMD Athlon Processor
Number of Memory Slot(s) 4
Supported Memory Standard(s) PC2-4200 (DDR2-533)
PC2-5300 (DDR2-667)
Maximum Installed Memory 4 GB
Expansion Slots PCI-E x16
Storage Controller Details 4x SATA
Audio Controller Realtek ALC883
Network Gigabit Ethernet
Connectors/Ports 24-pin ATX Power Connector
Chassis Fan Connector
CPU Fan Connector
Microphone
PS/2 Keyboard
PS/2 Mouse
RJ-45
USB 2.0
Connectors/Ports Details Back Panel I/O
One PS/2 keyboard port (purple)
One PS/2 mouse port (green)
One SPDIF (coaxial) out
One S-Video port
One VGA port
One IEEE 1394a
Four USB 2.0
One RJ-45 networking port
Audio ports
side speaker out (gray)
rear speaker out (black)
center
