Product Description
5188-3631 | HP | Micro-Atx System Board,socke Tlga775, Puffer2-Ul8eProduct Videos
Custom Field
Form Factor Micro ATX
CPU Socket Type LGA 775
Supported CPU(s) Intel Pentium 4 Processor
Clock Speed (Maximum) 3.6 GHz
FSB Speed (Maximum) 800 MHz
Chipset Intel 915P Express
South Bridge Chipset Intel ICH6
Number of Memory Slot(s) 4
Supported Memory Standard(s) PC2-3200 (DDR2-400)
PC2-4200 (DDR2-533)
Maximum Installed Memory 4 GB
Expansion Slots PCI-E x16
Expansion Slots Details One PCI Express x16 graphics
Three PCI
No AGP slot
Storage Controller SATA
Audio Controller Realtek ALC880
Network Fast Ethernet
Connectors/Ports 24-pin ATX Power Connector
8-pin 12V Power Connector
Parallel
PS/2 Keyboard
PS/2 Mouse
RJ-45
Connectors/Ports Details Back panel I/0
One PS/2 mouse port
One PS/2 keyboard port
One Parallel
One IEEE 1394
One RJ45 networking port
Six audio ports support 8-channel audio configuration
Four USB (2.0)
One S/PDIF in
One S/PDIF out
Internal connectors
One Floppy connector
